QC - AHP

Views: 0     Author: Site Editor     Publish Time: 2018-11-06      Origin: Site

QC flowchart

                           ----Aluminum Honeycomb Panel


Alu sheet Width/Length/ Diagonal checking

Alu sheet Degree checking

Alu sheet Thickness checking

Color Checking


AHP length checking

AHP width checking

AHP Diagonal checking

AHP Height checking
